TP-Link CPE610 Outdoor Access Point | 5GHz 300Mbps Wireless Bridge

Original price was: AED 190.Current price is: AED 160.

Model: TP-Link CPE610
Device Type: Outdoor CPE / Wireless Bridge
Antenna Type: Integrated Directional Antenna
Coverage Distance: Long-Range Point-to-Point Connectivity
Management Platform: Pharos Control
Operation Modes: Access Point, Client, Repeater, AP Router, AP Client Router (WISP)
Wireless Security: WPA/WPA2, AES Encryption
Outdoor Protection: Weatherproof Enclosure
Mounting: Pole Mountable
Application: Outdoor Wi-Fi & Wireless Bridging

About This Item

23 dBi High-Gain Antenna: The TP-Link CPE610 features a powerful 23 dBi directional antenna designed for long-distance wireless transmission, making it ideal for point-to-point and point-to-multipoint deployments.
5GHz Long-Range Speed: Operating on the 5 GHz frequency band, the CPE610 delivers stable wireless performance with speeds of up to 300 Mbps while minimizing interference from crowded 2.4 GHz networks.
Weatherproof Outdoor Design: Built with a durable weatherproof enclosure, the device is designed to withstand harsh outdoor environments and provide reliable operation in various conditions.
Multiple Operation Modes: Supports Access Point, Client, Repeater, AP Router, and WISP modes, allowing flexible deployment for different wireless networking needs.
Centralized Pharos Control: TP-Link’s Pharos Control enables easy centralized management of multiple CPE devices, simplifying monitoring, configuration, and maintenance.
Easy PoE Installation: Passive Power over Ethernet support allows power and data to run through a single cable, making installation faster and more convenient.
Long-Distance Wireless Bridge: Perfect for connecting remote buildings, surveillance systems, warehouses, campuses, farms, and other outdoor locations where wired connectivity is not possible.

SKU: 1021

Description
Review

Description for TP-Link CPE610 Outdoor Access Point

The TP-Link CPE610 Outdoor Access Point is a professional-grade outdoor wireless networking solution designed for long-range connectivity and reliable performance. Equipped with a high-gain 23 dBi directional antenna and operating on the 5 GHz frequency band, this TP-Link CPE610 Wireless Bridge delivers stable point-to-point and point-to-multipoint connections for businesses, campuses, warehouses, farms, and surveillance deployments.

Designed for outdoor environments, the CPE610 Access Point combines advanced wireless transmission technology with a rugged weatherproof enclosure to ensure dependable operation in challenging conditions. Its flexible deployment options allow it to function as an Outdoor Access Point, Client, Repeater, or Point-to-Point Bridge, making it suitable for a wide range of networking applications. With centralized management through TP-Link Pharos Control and Passive PoE support, the TP-Link CPE610 Outdoor CPE simplifies installation, monitoring, and maintenance while providing reliable long-range wireless connectivity.

HARDWARE FEATURES

Feature	Details
Processor	Qualcomm 560MHz CPU, MIPS 74Kc
Memory	64MB DDR2 RAM, 8MB Flash
Interface	1× 10/100Mbps Shielded Ethernet Port (LAN/PoE)
Power Supply	Passive PoE, 16–27VDC, 7.41 W
Dimensions	366 × 280 × 207 mm (14.4 × 11.0 × 8.1 in)
Antenna Gain	23 dBi
Antenna Beamwidth	9° (Azimuth), 7° (Elevation)
Protection	15KV ESD, 6KV Lightning Protection
Enclosure	Outdoor PC stabilized plastic, IP65 Rated
Certification	CE, FCC, IC, RoHS, IP65
Package Contents	Outdoor Wireless CPE, PoE Adapter, Mounting Straps, Cord
System Requirements	Windows, Mac OS, NetWare, UNIX, Linux
Operating Environment	Operating Temperature: -40°C to 70°C Humidity: 10% to 90%
Storage Environment	Temperature: -40°C to 70°C Humidity: 5% to 95%
Certifications	CE, FCC, UL, IC, GS, PSB, C-Tick, SAA, S-Mark, KC-Mark

Wireless Features

Feature	Details
Wireless Standards	IEEE 802.11a/n
Proprietary Protocol	TDMA Mode (Pharos MAXtream enabled)
Wireless Speeds	Up to 300Mbps (40MHz, Dynamic)
Frequency	5.15 ~ 5.85 GHz
Transmit Power	Max. 25dBm (Adjustable by 1dBm)

Software Features

Feature	Details
Network Configuration	WAN/LAN: Static, Dynamic, PPPoE, L2TP, PPTP
Security	SPI Firewall, Access Control, WPA/WPA2 Encryption
Wireless Configuration	MAXtream TDMA, Channel Width Control, DFS, WDS, Encryption Settings
Management	Pharos Control, Web-based UI, SNMP, DDNS, SSH
System Tools	LED Indicators, Monitoring Tools, Spectrum Analyzer, Speed Test Utility

POE Adapter Features

Feature	Details
Dimensions	85.8 × 43.9 × 29.7 mm
Interfaces	AC Jack, 2× 10/100Mbps Shielded Ethernet Ports
Power Status LEDs	Green Indicator
Input	100–240VAC, 50/60Hz
Output	24VDC, 0.5A Max, +4, 5 pins; -7, 8 pins (Support up to 60m)
Efficiency	>84.29%

Conclusion

The TP-Link CPE610 is an ideal choice for organizations seeking a dependable Outdoor Access Point and Wireless Bridge solution. Featuring a powerful 23 dBi directional antenna, 5 GHz wireless technology, and multiple operating modes, it provides the performance and flexibility required for professional outdoor networking deployments.

Whether you need a Point-to-Point Bridge to connect remote buildings, extend wireless coverage across large outdoor areas, or deploy a reliable 5GHz Outdoor Access Point, the TP-Link CPE610 Outdoor CPE delivers exceptional value, easy deployment, and long-range connectivity. Its durable design, centralized management capabilities, and proven wireless performance make it a trusted solution for enterprise, industrial, educational, and surveillance networking environments.

For further assistance, please contact Neumoon team via WhatsApp or email .
